# Displaying a record as a QR code

Turn a field value into a scannable QR code in each row of a screen flow Data Table, for example a link that opens the opportunity on a phone.

A sales manager walks through the open deals with the team on a shared screen. When someone wants to follow up on a deal from their phone, they scan the code on its row and the opportunity opens in the Salesforce mobile app or the browser. The Data Table draws a QR code from any field value; here the value is a link to the record.

<figure><img src="https://27923732-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F1FUd4apB9YHgCEMUFbVb%2Fuploads%2FZals4KQGzPSjoRJ14mrQ%2Fdata-table-tutorial-displaying-a-record-as-a-qr-code-result.png?alt=media" alt="A Data Table of opportunities with a QR code in each row that links to the opportunity"><figcaption><p>Each row carries a QR code that opens the opportunity.</p></figcaption></figure>

## Before you start

* A field that holds the value to encode. To open the record, create a **Formula** field on Opportunity, return type **Text**, named `Record Link`:

  ```
  LEFT($Api.Partner_Server_URL_260, FIND("/services", $Api.Partner_Server_URL_260)) & Id
  ```

  It returns your org's address followed by the record Id, for example `https://yourdomain.my.salesforce.com/006...`.
* Any other text works too: an order number, an asset serial number, a website.

## Steps

{% stepper %}
{% step %}

### Get the deals

1. In Flow Builder, add a **Get Records** element. Label it `Get Open Deals`.
2. Set **Object** to **Opportunity** and add the condition **Closed** equals `False`.
3. Store **All records**, and choose the fields to store: **Opportunity Name**, **Stage**, **Amount** and **Record Link**.

The flow now holds a collection of open deals, `{!Get_Open_Deals}`, that the screen can display.
{% endstep %}

{% step %}

### Add a screen with the Data Table

1. After **Get Open Deals**, add a **Screen** element. Label it `Review Deals`.
2. From the components list, drag the Avonni **Data Table** onto the screen.
3. Give it an API name such as `DealsTable`, then click **Open Component Builder**.
   {% endstep %}

{% step %}

### Connect the collection

1. In the **Properties** tab, under **Data Source**, choose **Variable**.
2. Select the `Get_Open_Deals` collection.
3. Drag **Opportunity Name**, **Stage**, **Amount** and **Record Link** from the **Fields** panel onto the table.
   {% endstep %}

{% step %}

### Render Record Link as a QR code

1. In the preview, click the chevron on the **Record Link** column header and choose **Type Attributes**.
2. Set **Type** to **QRcode**.
3. Set **Size** in pixels, for example `80px`. A plain number is read as pixels.
4. Leave **Encoding** on **ISO 8859 1** for a URL. Switch it to **UTF 8** when the value contains characters outside that set, such as Greek or Japanese text.
5. Optional: raise **Error Correction** from **L** to **M**, **Q** or **H** if the code may be printed small or scanned from a distance. Higher levels recover more damage but draw a denser code.
   {% endstep %}

{% step %}

### Save and test

Click **Done**, save the flow and run it with **Debug**.

Each row shows a QR code. Scan one with a phone camera: it opens the opportunity after the user logs in to Salesforce.
{% endstep %}
{% endstepper %}

## Troubleshooting

<details>

<summary>The QR code is too large and the rows get very tall</summary>

The row grows to fit the code. Lower **Size** (for example `60px`) or give the column a **Fixed Width** so the table keeps its layout.

</details>

<details>

<summary>The scan opens a page that does not exist</summary>

Check the value of **Record Link** on one record: it must start with `https://` and end with the record Id. If you encode a relative path such as `/006...`, the phone has no address to open.

</details>

## Related tutorials

* [How to add images on the Data Table](https://docs.avonnicomponents.com/flow/tutorials/components/data-table/how-to-add-images-onthe-data-table.md): show a picture from a URL field.
* [Displaying the record name as a link](https://docs.avonnicomponents.com/flow/tutorials/components/data-table/displaying-record-name-field-as-a-link.md): open the record from a click instead of a scan.
* [Learn the Basics](https://docs.avonnicomponents.com/flow/tutorials/components/data-table/learn-the-basics.md): the screen, the columns and the selection, step by step.


---
